SPAK-06
The AHU Kit is an adapter that connects custom air handling units to DVM S systems. It consists of a control PCB, an electronic expansion valve, pipe and air sensors, and works with standard AHUs or 100% outside air systems.
Full Description
AHU Kit is an adapter that allows the connection of custom, air handling units (AHU) to DVM S systems. AHU Kit consists of a control PCB, electronic expansion valve, pipe, and air sensors. AHU Kits can be used for standard air handling units or for 100% outside air systems.
Technical Specification
Nom heat exchanger capacity of AHU
54kBtu/h(6HP)
Heat exchanger volume (in.3)
117.2～178.2
Equivalent indoor unit capacity
54kBtu/h(6HP)
Allowed heat exchanger capacity (kBtu/h) * Heating
42.7/54.6/61.4
Allowed heat exchanger capacity (kBtu/h) * Cooling
38.2/47.8/54.6
Cooling capacity (Min/Max) (BTU/h)
54kBtu/h(6HP)
Indoor unit dimension (W*H*D)
17-7/32*6-35/64*2-13/32
